The ideal companion for the 1000 series.

PSU-1000 has been developed to over drive all 1000 series units, except the amps, to achieve the best resolution. Powered with Super Inductive Dual Choke hybrid design it features an inductive filter on the analogue stage and a dual choke design controlled by a double inductor driving both the negative and positive high-current stages.

The Dual Choke design – a Gold Note proprietary technology – perfectly filters the signal voltages to eliminate interference and electrical noise from the AC power system.

With its massive 1000 watt overall power supply it is capable of providing a shield from the AC power grid to achieve complete insulation, granting an ideal working environment to let the electronics perform at their best. The massive ultra-clean power thus generated enhances noise reduction, greater dynamic, better resolution and finer details guaranteeing the best realism and musicality.

PSU-1000 is powered by 5 transformers: 3 dedicated to the power supply, 1 for the inductive choke filter, 1 for the galvanic insulation of the audio stage.

PSU-1000 can match: CD-1000, DS-1000, P-1000 & PH-1000

TECHNICAL FEATURES:

5 low-noise voltage regulators

MAXIMUM VARIATION OF OUTPUT VOLTAGE:

0.05 %

LINE NOISE REJECTION:

>80dB

COMMON MODE NOISE REJECTION:

>80dB

ABSOLUTE PHASE CONTROL:

Selectable from front panel

FULL POWER RESPONSE TIME:

<2,5µsec

POWER CONSUMPTION:

100W

DYNAMIC POWER:

>200W

STAND BY POWER:

1W

POWER SUPPLY:

100-120V / 220-240V with auto sense, 50/60Hz

FUSE:

3,15 A F

DIMENSIONS:

425mm W | 135mm H | 360mm D

WEIGHT:

Kg. 21 net – Kg. 27 boxed

PSU CONNECTION CABLE:

1m
