Enclosure alignment
3-way bass reflex / acoustic suspension
Driver compliment
DPC-Array:26mm(3) Silk dome
Woofers:165mm(2) HPF diaphragms
Sensitivity
89.0dB / 2.83v / 1.0m
Impedance
4Ω nominal / 3.2Ω min
Response Linearity
80 - 20kHz +/-1.5dB window
Frequency Response (-10dB)
Bass reflex: 24 - 32kHz
Acoustic suspension: 38 - 32kHz
Typical In Room bass extension
Bass reflex: 21Hz
Acoustic suspension: 32Hz
Dimensions (HxWxD)
1100 x 230 x 350mm
43.3 x 9.0 x 13.7"
Weight
26.5 kg (58.3 lbs.)
Recommended Amplifier Power
100 - 250W RMS
SPL capability @1m (100-20kHz)
113.0dB peak <3% - 2nd, 3rd Harmonics
Certification
THX Dominus, THX Ultra
